HOME > products > Vacuum Booster

· Providing faster pumping speed and higher vacuum pressure
· Proved reliability to wide general industry
· Chemical, Plastic, Semi conductor, electricity, food manufacturing etc.
· Lower noise
· Applicable to use various kind of coating to improve internal abrasion and hardness.

items	Unit	KIB600	KIB1200	KIB1800	KIB2400	KIB3000	KIB5000
Nominal Displacement 50Hz(60Hz)	㎥/Hr	765(917)	1020(1220)	1700(2039)	2156(2587)	2832(3398)	5098(6117)
Effective Pumping Speed at 0.5 torr(60Hz)	㎥/Hr	680	900	1350	1713	Contact Kowel	Contact Kowel
Ultimate Pressure with Single Stage Backing Pump	Torr (Pa)	0.0007 (0.093)	0.0007 (0.093)	0.0007 (0.093)	0.0007 (0.093)	0.0007 (0.093)	0.0007 (0.093)
Motor Power	KW	4	4	4	7.5	7.5	15
Suction/Discharge Flange	ISO-DN	100	100	160	160	200	320
Oil Capacity	l	1	1	1.7	1.7	1.7	6.5
Weight	Kg	90	100	217	261	308	657

· Chemical and Petrochemical
  Evaporation, Degasing, Forming & Deforming, Packing, Condensation, Distillation, Polymerization & Estrification, Food Additives,   Plasticizer, etc.
· Fiber industry
  Dehydration, Distillation and Impregnant etc.
· Solvent recovery plants - Solvent recovering
· Food Industry
  Packaging, Boiling process, drying, pickup & conveying etc.
· Paper Industry
  Removing the moisture in manufacturing paper
· Mine field
  Extracting Methane and vacuum-forming of vacuum filtering aclc
· Timber industry
  Impregnant
· Mobile, machine, semi conductor etc.
